Fiber Optic Distribution Box | 8/12/16/24/48 Cores, IP-Rated, PLC Ready

Our fiber optic distribution boxes provide protected, organized handoff points for FTTH/FTTB and campus networks. Available for indoor wall-mount or outdoor pole/wall installation, each enclosure supports fusion splicing, adapter patching, and PLC splitter mounting to streamline feeder-to-drop distribution with neat cable management and service access.

Why Choose Our Distribution Boxes

IP-Rated Protection: Outdoor models feature sealed doors, gasketed entries, UV-resistant housings, and corrosion-resistant hardware for reliable weather performance.

Flexible Capacities: Standard options 8/12/16/24/36/48 cores; higher counts on request, with scalable splice tray stacks and interchangeable adapter plates.

Installer-Friendly Layout: Hinged covers, clear port labeling, bend-radius guides, and strain-relief points accelerate on-site work and reduce errors.

PLC Splitter-Ready: Dedicated mounting zones and fiber organizers for 1×N/2×N PLC splitters enable clean distribution without crowding.

OEM/ODM Support: Custom logos, colorways, port maps, adapter panel configurations, labeling, and kit-packing to match carrier standards.

Typical Applications

FTTH/FTTB distribution and drop terminations in apartments, MDUs, and residential neighborhoods.

Outdoor curb, pole, or wall handoff from feeder to multiple subscriber drops.

Floor riser and building cross-connect nodes for campuses and office towers.

Small-cell, CCTV, and IoT fiber termination points requiring secure splicing and patching.

Product Types

Indoor Wall-Mount Distribution Box: Compact footprint for telecom rooms or floor risers; accepts splice tray and small adapter panel.

Outdoor IP-Rated Distribution Box: UV-stabilized ABS/PC or powder-coated metal; lockable cover, cable glands/knockouts, pole/wall brackets.

Splitter-Integrated Box: Pre-defined positions for PLC modules with organizer rings and labeled ports for fast service activation.

High-Capacity Box: Multi-tray stack, removable adapter panels, and enlarged routing space for dense feeder-to-distribution cross-connect.

Specifications Overview

Capacity: 8/12/16/24/36/48 cores standard; custom higher counts available.

Adapters: LC/SC/FC/ST simplex or duplex panels; APC/UPC compatible as required.

Splicing: Heat-shrink or mechanical splice trays; integrated fiber organizers and splice holders.

Splitter Support: 1×N and 2×N PLC splitter mounting slots with protected routing channels.

Sealing & Ratings: Model-dependent IP54–IP66 targets for outdoor units; gasketed doors and sealed entries.

Materials: High-impact ABS/PC for outdoor UV performance; metal options with anti-corrosion coating; indoor flame-retardant variants.

Cable Entry: Gland/knockout options for feeder/drop; built-in strain-relief and bend-radius management.

Operating Range: Typical −40 °C to +70 °C for outdoor; refer to datasheet for exact rating.

Selection Guide

MDU or Floor Riser: Choose an indoor wall-mount box with 8–24 cores and a mixed LC/SC adapter plate.

Pole/Outdoor Handoff: Select an IP-rated model with lockable cover, cable glands, and UV-stable housing.

Splitter Distribution: Use PLC-ready boxes with labeled ports and dedicated splitter brackets to simplify activation.

High Fan-Out: Opt for high-capacity models with multi-tray stacks and removable adapter panels.

Installation & Management

Route feeder through the gland, secure with strain-relief, and maintain bend radius using internal guides.

Mount splice trays, manage pigtails on organizers, and label adapters for fast identification and service records.

Install PLC splitter, verify port mapping, and perform IL/RL tests prior to close-out; document labels for future maintenance.

Customization & Services

Branding and labeling (logo, port map, barcode/QR), adapter layouts, splitter pre-install, color/finish, and kit-packing with pigtails, adapters, and glands.

Engineering support for BOM planning, optical budget checks, port assignment, and accessory lists matched to your rollout plan.

Supply readiness: stock on common SKUs, expedited builds for customs, staged deliveries, and export-grade packaging.

Ordering Information

Please specify: Installation type (indoor/outdoor), capacity (port/core count), adapter type (LC/SC/FC/ST; UPC/APC), splitter requirement (1×N/2×N), cable entry style (gland/knockout), locking option, labeling/branding, and packaging needs.

Frequently Asked Questions (FAQ)

Q1: Can you pre-install PLC splitters, adapters, and pigtails? Yes—boxes can ship pre-assembled to shorten on-site splicing and activation time.

Q2: What IP rating do outdoor distribution boxes offer? Depending on the model, outdoor units target IP54–IP66 with gasketed doors and sealed cable entries.

Q3: Do you provide OEM/ODM services? Absolutely—custom logos, port labeling, adapter layouts, and packaging can be tailored to carrier standards.

Q4: Samples available? YES！

Q5: What warranty and after-sales support do you offer? Standard 2-year warranty, free returns for quality issues within 3 months, 24-hour inquiry response, and order tracking from production to delivery.

Q6: Can the enclosure be locked? Many outdoor models support keyed locks or seal tags—confirm the requirement when requesting a quote.

Request a Quote

Request Your Quote or contact our team to match enclosure type, capacity, and accessories to your FTTH deployment.
