ODF Distribution Frame | LGX, Rack-Mount, High-Density, Scalable

Our Optical Distribution Frames (ODF) offer scalable, modular solutions for managing fiber splicing, patching, and routing in high-density environments. Designed in standard LGX or 19-inch rack formats, these frames streamline fiber organization and network flexibility in data centers, telecom rooms, and campus networks.

Key Benefits

Modular Design: Supports LGX-style cassettes, splice trays, and patch panels—expand as your network grows.

Sleek & Accessible: Rack-mount layouts with swing-out or front-rear access for organized cable routing and easy maintenance.

High-Density Utilization: Accommodates up to 144 ports per rack-unit with optional high-density adapters or cassette modules.

Robust Construction: Steel chassis, powder-coated surface, and cable strain relief for durable deployment.

OEM/ODM Options: Custom color, logos, cassette layouts, labeling, packaging, and accessory bundling available.

Typical Applications

Fiber cross-connect and patching in central offices, MDFs, and IDFs.

Pre-terminated or field-spliced fiber aggregation points in data centers.

Campus backbone consolidation with scalable expansion frames.

Product Variants

LGX Modular ODF: Accepts LGX-style cassettes for mixed splice and patch configuration flexibility.

Rack-Mount Drawer ODF: Slide-out trays with integrated adapter panels for ease of access and maintenance.

High-Density ODF: Multi-layer frame designed to house maximum fiber ports in minimal rack space.

Specifications Overview

Form Factors: 19-inch rack, LGX modular chassis.

Port Density: Up to 144 adapter ports (LC/SC/FC/ST) per 1RU depending on cassette layout.

Splicing: Capability to mount 1–4 splice trays per cassette or drawer.

Material: Heavy-duty steel frame; grounded design; cable management arms and ducting.

Mounting: Fixed, swing-out, or sliding drawer options for workspace efficiency.

Selection Guide

Medium installations: Use single or dual LGX chassis with mix of splice cassettes and patch modules.

High-density needs: Go for high-density drawer style ODF with LC duplex modules for maximum port count.

Easy access setups: Prefer swing-out or drawer frames for front/back servicing in constrained racks.

Customization & Services

Customize color, labeling, logo, port and cassette layout, included modules (cassettes, adapters, splice trays), and packaging per deployment needs.

Engineering support available for port planning, fiber routing schematics, optical budget checks, and accessory lists.

Fast production of standard SKUs, expedited builds for custom frames, and staged deliveries for rollout alignment.

Ordering Information

Please specify: Frame type (LGX/rack/drawer), desired capacity (ports/splice trays), cassette/adapter types, mounting style (fixed/swing-out/drawer), custom branding, and delivery needs.

Frequently Asked Questions (FAQ)

Q1: Can I mix splice and patch modules? Yes—LGX-style ODF allows combining splice trays, patch cassettes, and hybrid units in the same chassis.

Q2: Are high-density options available? Yes—drawer-style ODFs support up to 144 LC ports per rack-unit for maximum efficiency.

Q3: Do you offer customized labeling and branding? Absolutely—OEM/ODM options allow for logos, cable numbering, cassette maps, and color variants.

Q4: Can I get a sample or mock-up? Sample modules or mock-up frames can be provided for qualified evaluations; please inquire.

Q5: What is the lead time for custom ODFs? Standard versions ship quickly; custom configurations are fast-tracked, with options for split shipments.

Request a Quote

Request Your Quote or contact our team to configure your ideal ODF solution for efficient and future-proof fiber management.
